ST SPIRIT1 QTR 470M 868M Iot Wifi Module Cansec Wireless S2SPI-UA-A

Name: ST SPIRIT1 QTR 470M 868M Iot Wifi Module Cansec Wireless S2SPIUAA
Brand: Cansec Wireless
Price: 2.68 USD

Quality ST SPIRIT1 QTR 470M 868M Iot Wifi Module Cansec Wireless S2SPI-UA-A for sale

Brand Name : Cansec Wireless

Model Number : S2SPI-UA-A

Place of Origin : Beijing

MOQ : 100

Price : USD 2.68$ per piece

Payment Terms : T/T

Supply Ability : 2000000 pieces per year

Delivery Time : 5~8 weeks

Packaging Details : Box for 1000 pieces Package size: 40*34*20 cm Gross weight: 5.000 kg

size : 15mm*22mm*3.2mm

TX Power : 14dBm

RX sensitivity : -130dBm

TX current : 40mA

RX current : 9mA

Standby current : 1uA

Antenna : UFL Connector

Chipset : S2-LP by ST

Frequency : 434/868/915MHz

Reach : 230m max

Working Tempurature : -20~+70℃

Contact Now

Cansec Wireless S2SPI-UA-A ST SPIRIT1 QTR 434M/470M/868M/915M smart home IoT Solution Low Power Consumption Module

ST SPIRIT1 QTR 470M 868M Iot Wifi Module Cansec Wireless S2SPI-UA-A

868MHz

Parameter		Min	Typ	Max	Unit
Operating Voltage		1.8	-	3.6	V
Operating Temperature		-20	-	+70	℃
Current Consumption	Sleep Mode	-	-	1	uA
	Receive mode	-	8	9	mA
	Transmit Mode	-	38	40	mA
TX Power (For Carrier)		-	-	14	dBm
RX Sensitivity (For Lora Modulation)		-	-	-130	dBm
Distance		HA:110 UA:230			m

434MHz

Parameter		Min	Typ	Max	Unit
Operating Voltage		1.8	-	3.6	V
Operating Temperature		-20	-	+70	℃
Current Consumption	Sleep Mode	-	-	1	uA
	Receive mode	-	8.2	9	mA
	Transmit Mode	-	21	24	mA
TX Power (For Carrier)		-	-	14	dBm
RX Sensitivity (For Lora Modulation)		-	-	-130	dBm
Distance		HA:110 UA:230			m

Cansec Wireless S2SPI-UA-A ST SPIRIT1 QTR 434M/470M/868M/915M smart home IoT Solution Low Power Consumption Module

Description

S2SPI-HA/UA/NA-A Module is designed based on S2-LP. S2-LP is a high performance ultra-low power RF transceiver, intended for RF wireless applications in the sub-1 GHz band. It is designed to operate in both the license-free ISM and SRD frequency bands at 433, 868 and 920 MHz, but can also be programmed to operate at other additional frequencies in the 430-470MHz, 860-940 MHz bands.
The S2-LP can be used in systems with channel spacing of 12.5/25 kHz enabling. The narrow band operations. The S2-LP shows an RF link budget higher than 140dB for long communication ranges and meets the regulatory requirements applicable in territories worldwide, including Europe, Japan, China and the USA.
Application
- Sensors to Cloud
- Smart metering
- Home energy management systems
- Wireless alarm systems
- Smart home
- Building automation
- Industrial monitoring and control
- Smart lighting systems


ST SPIRIT1 QTR 470M 868M Iot Wifi Module Cansec Wireless S2SPI-UA-A

FAQ
 Q1: Are you a factory or trade company?
 A1: We are a professional factory with 25 years experience.
 Q2: Can you accept OEM/ODM?
 A2: Sure, we have rich OEM&ODM experience.
 Q3: Do you have quality assurance?
 A3; Each of our products has undergone quality testing and has two years of free after-sales service.
