Iot Control ASR6501 Chipset Microchip Lora Module

Name: Iot Control ASR6501 Chipset Microchip Lora Module
Brand: Cansec Wireless
Price: 4.90 USD

Quality Iot Control ASR6501 Chipset Microchip Lora Module for sale

Brand Name : Cansec Wireless

Model Number : ASR6501

Place of Origin : Beijing

MOQ : 1000

Price : USD 4.90$ per piece

Payment Terms : T/T

Supply Ability : 20000000 units per year

Delivery Time : 5-8 weeks

Packaging Details : Three layers of protection anti-static bag & moisture-proof & cardboard box ensure transportation safety

Chipset : ASR6501

Application : IoT

Size : 16*23*2.8mm

Operating Temperature : -20 - 70℃

Operating Voltage : 1.8-3.7V

TX Power : 21dBm

RX Sensitivity : -148dBm

Sleep Current Consumption : 3μA

Frequency : 434, 868, 915 MHz

name : Iot Control ASR6501 Chipset Microchip Lora Module

Contact Now

Iot Control ASR6501 Chipset Microchip Lora Module

Smart City & Farming Use IoT Control Module Cansec LoRawan LRW2020 ASR6501 Wireless Receiver 915Mhz LoRa Module

Parameter		Min	Typ	Max	Unit
Operating Voltage		1.8	3.3	3.7	V
Operating Temperature		-20	-	+70	℃
Current Consumption	Sleep Mode(Without RF Config Retention, with RTC)	-	3	4	uA
	Receive mode	-	12	-	mA
	Transmit Mode (@+20dBm, Carrier)	-	120	-	mA
TX Power (For Carrier)		-	20	21	dBm
RX Sensitivity (For Lora Modulation)		-	-	-140	dBm
Distance		2			Km

Smart City & Farming Use IoT Control Module Cansec LoRawan LRW2020 ASR6501 Wireless Receiver 915Mhz LoRa Module

LRW2020UA-A module is designed based on SX1262 and MCU which is a general LoRa Wireless Communication Chipset.The module with an AT instructions firmware, easy to use, reduce the development process of personnel.

Iot Control ASR6501 Chipset Microchip Lora Module

FAQ
Q1: Are you a factory or trade company?
 A1: We are a professional factory with 25 years experience.
 Q2: Can you accept OEM/ODM?
 A2: Sure, we have rich OEM&ODM experience.
 Q3: Do you have quality assurance?
 A3; Each of our products has undergone quality testing and has two years of free after-sales service.
